Battery Monitoring System

MT99BT

MT99BT Battery Monitoring Module
1. Monitor battery string voltage, charge, and discharge current
2. Calculate the battery string SOC.
3. Auto-Balancing
4. Auto-sensing for the Battery Sensor's ID Address
5. Setpoint Alarm (Upper Limit and Lower Limit)
6. Data Collection
7. Data Uploading Function via Build-in RS485 (Modbus-RTU) and Ethernet (Modbus-TCP or SNMP)
8.Check Battery String Stat

Specification Product pictures Data download

Technology Parameter
Application	DC Power system (Telecome)
Rated Iput Voltage	24VDC or 48VDC, Range: 20V-60VDC
Measuring Voltage	0-800V (Accuracy:±0.5%)
Measuring Current	-1000A - +1000AV (by Hall Sensor,Accuracy:±2.0%)
Power Consumption	＜2W
Up-link Communication	1 Ethernet port(10/100M),Modbus-TCP /SNMP protocal 1 RS485 port, Modbus-RTU protocal,Baudrate:9600bps,19200bps,38400bps
Down-link Communication	2RJ11 ports, each port connect Max.60pcs batterirs, total Max.120pcs batteries
